Axis Q6075-S User Manual

AXISQ6075-SPTZNetworkCamera
Specifications
•Digitaloutput—ForconnectingexternaldevicessuchasrelaysandLEDs.Connecteddevicescanbeactivatedby
theVAPIX®ApplicationProgrammingInterfaceorfromthedevice’swebinterface.
•Digitalinput—Forconnectingexternaldevicesthatcantogglebetweenanopenandclosedcircuit,forexample
PIRdetectors,door/windowcontacts,andglassbreakdetectors.
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mA
Digitalinput–Connecttopin1toactivate,orleave
oating(unconnected)todeactivate.
0tomax30VDC
Congurable(Input
orOutput)
3–4
Digitaloutput–Internallyconnectedtopin1(DC
ground)whenactive,andoating(unconnected)when
inactive.Ifusedwithaninductiveload,e.g.arelay,a
diodemustbeconnectedinparallelwiththeload,for
protectionagainstvoltagetransients.
0tomax30VDC,open
drain,100mA
FunctionPinNotes
Specications
0VDC(-)
1
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
3.3VDC
Maxload=250mA
Digitalinput–Connecttopin1toactivate,orleave
oating(unconnected)todeactivate.
0tomax40VDC
Congurable(Input
orOutput)
3–6
Digitaloutput–Internallyconnectedtopin1(DC
ground)whenactive,andoating(unconnected)when
inactive.Ifusedwithaninductiveload,e.g.arelay,a
diodemustbeconnectedinparallelwiththeload,for
protectionagainstvoltagetransients.
0tomax40VDC,open
drain,100mA
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mA
85
