Axis Q6075-S User Manual

AXISQ6075-SPTZNetworkCamera
Specifications
Digitalinput–Connecttopin1toactivate,orleave
oating(unconnected)todeactivate.
0tomax30VDC
Congurable(Input
orOutput)
3–6
Digitaloutput–Internallyconnectedtopin1(DC
ground)whenactive,andoating(unconnected)when
inactive.Ifusedwithaninductiveload,e.g.arelay,a
diodemustbeconnectedinparallelwiththeload,for
protectionagainstvoltagetransients.
0tomax30VDC,open
drain,100mA
1
0VDC(-)
2
DCoutput12V,max50mA
A
I/Oconguredasinput
B
I/Oconguredasoutput
1
0VDC(-)
2
DCoutput3.3V,max250mA
A
I/Oconguredasinput
86

Axis Q6075-S Specifications

General

Brand	Axis
Model	Q6075-S
Category	Security Camera
Language	English
