Milling head
casting
Rise & Fall drive
screw dog
Gear change knob
Motor
Fine feed control
Coarse feed scale
Feed handle
Head clamp
High ratio
Low ratio
Fine feed thimble
Normal
Fine feed
Chuck
Gearbox
Fine feed engage knob
Thimble
MACHINE ILLUSTRATION OF THE MILL
