4-24
4.7.6 Shut-Off Count
Counts the total number of times that the valve is fully closed.
Select [Diagnostics] >> [Valve Diagnostic Information] >> [Shut-Off Count]. You will
be able to check or modify the following items. To change a value, select the item and
then change it.
■ Shut-Off Count
Displays and allows modification of the total fully closed count.
■ Update Shut-Off Count
Updates the fully closed count to the latest value.
• Select the [Update Shut-Off Count] menu to execute the update.
■ Shut-Off Count Threshold
Displays and allows modification of the threshold. An alarm occurs if the fully closed
count reaches or exceeds this value.
■ Shut-Off Count Alarm Enabled
Displays and allows modification of the alarm enabled/disabled status. If the status is
Enabled, alarms will occur, and if the status is Disabled, alarms will not occur.
4.7.7 Max Travel Speed
The maximum operating speed per unit time of the valve.
Select [Diagnostics] >> [Valve Diagnostic Information] >> [Max Travel Speed]. You will
be able to check or modify the following items. To change a value, select the item and
then change it.
■ Max Tvl Speed +, Max Tvl Speed −
Displays and allows modification of the maximum operating speed on the “+” side and
“−” side.
■ Update Max Tvl Speed
Updates the maximum operating speed to the latest value.
• Select the [Update Max Tvl Speed] menu to execute the update.
■ Clear Max Tvl Speed
Deletes the maximum operating speed.
• Select the [Clear Max Tvl Speed] menu to clear the count.
■ Max Tvl Speed Threshold +, Max Tvl Speed Threshold −
Displays and allows modification of the thresholds on the “+” side and “−” side. An
alarm occurs if the maximum operating speed is outside the range specified by the
thresholds.
■ Max Tvl Speed Alarm Enabled
Displays and allows modification of the alarm enabled/disabled status. If the status is
Enabled, alarms will occur, and if the status is Disabled, alarms will not occur.
