Azbil AVP201 User Manual

A-14
Accessory Selection
(6) (7) (8) (9) - (10)
(6) Pressure
regulator
with filter
Without regulator X
Model KZ03 pressure regulator with lter (Mounted on positioner) *
5
1
(7) Cable length
3 m 3
5 m 5
10 m T
20 m W
(8) (9) Actuators
(for bracket)
No mounting plate X X
Single-acting
actuators
PSA1, PSA2, PSK1 Y S
New model of PSA3, PSA4 / VA1 to VA3 produced after 2000 *
6
Y Q
Previous model of PSA3, PSA4 for existing valves produced on/before 1999 Y Y
PSA6 / VA4 to VA6 produced after Apr.’83 *
6
Y L
HA1 Y A
HA2, HA3, HL2, HL3 Y T
HA4, HL4 Y N
HK1, VM1 *
7
(material SS400 zinc plated) Y K
VR1 Y V
VR2, VR3 Y R
VR3H Y 6
RSA1 Y F
RSA2 Y U
GOM83S, GOM84S, GOM103S Y G
GOM124S Y M
VA1 - VA3 (for old-model motion connectors) produced on/before Apr.‘83 800-1, 800-3 *
8
Y W
VA4, VA5 (for old-model motion connectors) produced on/before Apr.‘83 800-4, 800-5 *
8
Y J
Actuators of other manufacturers
See Table 6
Double-
acting
actuators
VP5, 6 *
9
Y 1
SLOP560, 1000, 1000X *
9
*
10
Y 2
SLOP1500, 1500X *
9
*
10
Y 3
DAP560, 1000, 1000X *
9
*
10
Y 4
DAP1500, 1500X *
9
*
10
Y 5
GOM44L, 44LM (Springless horizontal) *
9
G 1
GOM410L, 410LM (Springless horizontal) *
9
G 2
GOM64L, 64LM (Springless horizontal) *
9
G 3
GOM66L, 66LM (Springless horizontal) *
9
G 4
GOM610L, 610LM (Springless horizontal) *
9
G 5
GOM84L, 84LM (Springless horizontal) *
9
G 6
GOM86L, 86LM (Springless horizontal) *
9
G 7
GOM810L, 810LM (Springless horizontal) *
9
G 8
GOM1210L, 1210LM (Springless horizontal) *
9
G T
GOM1510L, 1510LM (Springless horizontal) *
9
G U
GOM44L, 44LM (Springless horizontal) with restoration feedback lever *
9
*
11
G E
GOM410L, 410LM (Springless horizontal) with restoration feedback lever *
9
*
11
G F
GOM64L, 64LM (Springless horizontal) with restoration feedback lever *
9
*
11
G G
GOM66L, 66LM (Springless horizontal) with restoration feedback lever *
9
*
11
G H
GOM610L, 610LM (Springless horizontal) with restoration feedback lever *
9
*
11
G J
GOM84L, GOM84LM (Springless horizontal) with restoration feedback lever *
9
*
11
G K
GOM86L, GOM86LM (Springless horizontal) with restoration feedback lever *
9
*
11
G L
GOM810L, GOM810LM (Springless horizontal) with restoration feedback lever *
9
*
11
G M
GOM1210L, GOM1210LM (Springless horizontal) with restoration feedback lever *
9
*
11
G N
GOM1510L, GOM1510LM (Springless horizontal) with restoration feedback lever *
9
*
11
G P
GOM84LM (Springless vertical) *
9
G B
GOM124LM (Springless vertical) *
9
G C
Actuators of other manufacturers
See Table 7
(10) Option
None M
Explosion-proof universal elbow (SUS304 G1/2) (1) L
Explosion-proof universal elbow (SUS304 G1/2) (2) A
Mounting screw Unify (5/16-18UNC) (Electrical conduit connection only supports 1/2NPT) C
Mounting screw Unify (5/16-18UNC) (Electrical conduit connection only supports 1/2NPT) K
Mounting screw Unify (5/16-18UNC) (Electrical conduit connection only supports 1/2NPT) H
Mounting screw Unify (5/16-18UNC) (Electrical conduit connection only supports 1/2NPT) J
Mounting screw Unify (5/16-18UNC) (Electrical conduit connection only supports 1/2NPT) U
Mounting screw Unify (5/16-18UNC) (Electrical conduit connection only supports 1/2NPT) 8
Mounting screw Unify (5/16-18UNC) (Electrical conduit connection only supports 1/2NPT) W
*5 Select model AVP200/AVP201 only when the direction of drain of the pressure regulator with lter on the control valve is downward (ground).
*6. Select “YW” or “YJ” for old-type motion connectors. (Produced on/before Apr.’83)
*7. In case “VM” type actuator is required following conditions,
1. select model “VCT” for the body,
2. the existing positioner should be HEP or VPE,
3. yoke should be model HK. If another specication is required, contact your sales representative.
*8. Consult a sales representative in case of no mounting hole on the side of valve yoke.
*9. For the double acting actuator, a reversing relay unit required.
*10. If the valve body is for VFR (FloWing) or a buttery valve, for the mounting bracket requirement consult to our sales.
*11. Select the option with the restoration feedback lever, if GOM manufactured before April, 1988. Select the option ‘8’ (Accessory bracket for GOM actuator - Use the
case of existing GOP) if the existing control valve assembled with GOP and the accessories such as the Lock-up valves and solenoid valves.
