Azbil AVP201 User Manual

A-16
Table 7. Mounting bracket for double acting actuator
(8)(9) Mounting bracket for pneumatic actuator Code
NIHON KOSO 6300 series 63A2, AT series AT20 *
1
T2
NIHON KOSO 6300 series 63A3, B2, BA, B3, BB, B5, AT series AT-30, 200, 250, 300, 350, 500 *
1
T3
NIHON KOSO 6300 series 63A4, A5, A6, AT series AT40, AT50, AT60 *
1
T4
NIHON KOSO 6300 series AT series AT25 *
1
T5
NIHON KOSO TC-500 series TC-520W *
1
*
2
TP
NIHON KOSO TC-700 series TC-713W *
1
TS
Pentair Valve and Control Japan AK09, AK12, AK15 *
1
KA
Pentair Valve and Control Japan AG06, AGN06 *
1
KG
Pentair Valve and Control Japan AG09, AGN09 *
1
KH
Pentair Valve and Control Japan AG13, AGN13 *
1
KJ
Pentair Valve and Control Japan AW13 *
1
KV
Pentair Valve and Control Japan AW17 *
1
KW
Pentair Valve and Control Japan AW20 *
1
KT
KITZ B series B-2 *
1
B2
KITZ B series B-3 *
1
B3
KITZ B series B-4 *
1
B4
KITZ B series B-5 *
1
B5
KITZ B series B-6 *
1
B6
Xomox (EL-O-MATIC) E25, 40, 65, 100, 200, 350 *
1
RA
Xomox (EL-O-MATIC) E600, 950, 1600, P2500, P4000 *
1
RB
Tomoe Valve Z series Z-06, 08, 11, 13 *
1
EA
Tomoe Valve T-matic 3I-1, 2, 3, 4 *
1
E3
T. V. VALVE AT4-80 *
1
V1
T. V. VALVE AT4-100 *
1
V2
T. V. VALVE AT4-120 *
1
V3
T. V. VALVE AT4-150 *
1
V4
T. V. VALVE AT4-180 *
1
V5
*1. For the double acting actuator, a reversing relay unit required.
*2. Confirm that boss’s pitch of the actuator side is 69 mm, if it is required to assemble the mounting bracket to the actuator.
Table 8. Standard travel range and accuracy
Actuator Travel (mm) accuracy (%F.S.)
PSA1, 2 14.3, 20, 25 1
PSA3, 4 20, 38 1
HA1 6, 8, 10 3
14.3, 25 1
HA2 10 3
14.3, 25, 38 1
HA3 14.3 3
25, 38, 50 1
HA4 14.3 3
25, 38, 50, 75 1
VA 5 25, 37.5, 50, 75, 100 1
VA 6
PSA6, 7
14.3 3
25, 37.5, 50, 75, 100 1
HK1
PSK1
10 3
19 1
