4-10
Paking Flange Nut
Packing Flange
Packing Follower
Stud Bolt
Bonnet
Gland Packing
H
ex Nut (1)
Gasket (1)
Gasket (2)
Guide Ring
Valve Stem
Valve Plug
Stud Bolt
Valv
e Body
Seat Ring
Figure 4-6 Model HAV Control Valves
