Azbil HLS Series User Manual

6-2
Model HA3D -> Model HA3R
Part name Q'ty
For stroke
14.3mm
For stroke
25mm, 38mm
For stroke
38mm
Seal washers +2 82521069-102 82521069-102 82521069-102
Rod packing +1 82521067-102 82521067-102 82521067-102
Rod unit +1 82521431-201
82521431-202 (25mm)
82521431-204
82521431-203 (38mm)
Rain cap +1 82553334-101 82553334-101 82553334-101
Rod (-1) 82521428-101
82521428-102 (25mm)
82521428-104
82521428-103 (38mm)
Model HA4D -> Model HA4R
Part name Q'ty For stroke 25mm
For stroke
38mm, 50mm, 75mm
Seal washers +2 82521069-103 82521069-103
Rod packing +1 82521067-103 82521067-103
Rod unit +1 82521431-302 82521431-303
Rain unit (-1) 82521429-102
82521429-103 (38mm)
82521429-104 (50mm)
82521429-105 (75mm)
Rain cap +1 82553334-101 82553334-101
Flat washers (-2) 82592131-201 82592131-201
