6-4
Model HA3R -> Model HA3D
Part name Q'ty
For stroke
14.3mm
For stroke 25mm, 38mm For stroke 50mm
Seal washers (-2) 82521069-102 82521069-102 82521069-102
Rod packing (-1) 82521067-102 82521067-102 82521067-102
Rod unit +1 82521428-101
82521428-102 (25mm)
82521428-104
82521428-103 (38mm)
Rod (-1) 82521431-201
82521431-202 (25mm)
82521431-204
82521202-203 (38mm)
Rain cap (-1) 82553334-104 82553334-104 82553334-104
Model HA4R -> Model HA4D
Part name Q' ty For stroke 25mm
For stroke
38mm, 50mm, 75mm
Seal washers (-2) 82521069-103 82521069-103
Flat washaers +2 82592131-201 82592131-201
Rod packing (-1) 82521067-103 82521067-103
Rod unit (-1) 82521431-302 82521431-303
Rod +1 82521429-102
82521429-103 (38mm)
82521429-104 (50mm)
82521429-105 (75mm)
Rain cap (-1) 82553334-104 82553334-104
For the conversion procedure, refer to “Disassembly and Assembly”
