Chapter 2. PARA BANK SETTINGS
Display Loop number
(auxiliary display)
Item PID
value
Settings and descriptions Initial
value
User
setting
Remarks
P- 16 L. 1.
Proportional band 16 Same as PID1 5.0 Same as PID1
I - 16 L. 1.
Integral time 16 120
d- 16 L. 1.
Derivative time 16 30
OL- 16 L. 1.
Output low limit 16 0.0
OH- 16 L. 1.
Output high limit 16 100.0
rE- 16 L. 1.
Manual reset 16 50.0
P- 16C L. 1.
Proportional band for cool side 16 5.0
I - 16C L. 1.
Integral time for cool side 16 120
d- 16C L. 1.
Derivative time for cool side 16 30
OL. 16C L. 1.
Output low limit for cool side 16 0.0
OH. 16C L. 1.
Output high limit for cool side 16 100.0
 Loop 2 PID bank (L 2.PI D)
Display Loop number
(auxiliary display)
Item PID
value
Settings and descriptions Initial
value
User
setting
Remarks
p-0 1 L.2.
Proportional band 1 0.1 to 3200.0 % 5.0
I -0 1 L.2.
Integral time 1 0 to 32000 s, 0.0 to 3200.0 s or 0.00 to
320.00 s (no integral control action
when set at 0, 0.0 or 0.00.)
120 The decimal point position is
determined by the decimal
point positions for the integral
time and derivative time.
d-0 1 L.2.
Derivative time 1 0 to 32000 s, 0.0 to 3200.0 s or 0.00 to
320.00 s (no derivative control action
when set at 0, 0.0 or 0.00.)
30
OL-0 1 L.2.
Output low limit 1 -10.0 to +110.0 % 0.0
Oh-0 1 L.2.
Output high limit 1 100.0
re-0 1 L.2.
Manual reset 1 50.0
p-0 1c L.2.
Proportional band for cool side 1 0.1 to 3200.0 % 5.0
i -0 1c L.2.
Integral time for cool
side
1 0 to 32000 s, 0.0 to 3200.0 s or 0.00 to
320.00 s (no integral control action
when set at 0, 0.0 or 0.00.)
120 The decimal point position is
determined by the decimal
point positions for the integral
time and derivative time.
d-0 1C L.2.
Derivative time for
cool side
1 0 to 32000 s, 0.0 to 3200.0 s or 0.00 to
320.00 s (no derivative control action
when set at 0, 0.0 or 0.00.)
30
OL.0 1C L.2.
Output low limit for cool side 1 -10.0 to +110.0 % 0.0
OH.0 1C L.2.
Output high limit for cool side 1 100.0
P-02 L.2.
Proportional band 2 Same as PID1 5.0 Same as PID1
I -02 L.2.
Integral time 2 120
d-02 L.2.
Derivative time 2 30
OL-02 L.2.
Output low limit 2 0.0
OH-02 L.2.
Output high limit 2 100.0
rE-02 L.2.
Manual reset 2 50.0
P-02C L.2.
Proportional band for cool side 2 5.0
I -02C L.2.
Integral time for cool side 2 120
d-02C L.2.
Derivative time for cool side 2 30
OL.02C L.2.
Output low limit for cool side 2 0.0
OH.02C L.2.
Output high limit for cool side 2 100.0
P-03 L.2.
Proportional band 3 Same as PID1 5.0 Same as PID1
I -03 L.2.
Integral time 3 120
d-03 L.2.
Derivative time 3 30
OL-03 L.2.
Output low limit 3 0.0
OH-03 L.2.
Output high limit 3 100.0
rE-03 L.2.
Manual reset 3 50.0
P-03C L.2.
Proportional band for cool side 3 5.0
I -03C L.2.
Integral time for cool side 3 120
d-03C L.2.
Derivative time for cool side 3 30
OL.03C L.2.
Output low limit for cool side 3 0.0
OH.03C L.2.
Output high limit for cool side 3 100.0
P-04 L.2.
Proportional band 4 Same as PID1 5.0 Same as PID1
I -04 L.2.
Integral time 4 120
d-04 L.2.
Derivative time 4 30
OL-04 L.2.
Output low limit 4 0.0
OH-04 L.2.
Output high limit 4 100.0
rE-04 L.2.
Manual reset 4 50.0
P-04C L.2.
Proportional band for cool side 4 5.0
I -04C L.2.
Integral time for cool side 4 120
d-04C L.2.
Derivative time for cool side 4 30
OL.04C L.2.
Output low limit for cool side 4 0.0
OH.04C L.2.
Output high limit for cool side 4 100.0
