Chapter 2. PARA BANK SETTINGS
Display Logical opera-
tion number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
bF-0 1 15.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 15.
Input assignment A 1024
bF-03 15.
Input assignment B
bF-04 15.
Input assignment C
bF-05 15.
Input assignment D
bF-06 15.
Input bit polarity A 0
bF-07 15.
Input bit polarity B
bF-08 15.
Input bit polarity C
bF-09 15.
Input bit polarity D
bF- 10 15.
ON delay time 0.0
bF- 1 1 15.
OFF delay time
bF- 12 15.
Polarity 0
bF- 13 15.
Latch 0
bF-0 1 16.
Operation type Same as logical operation 1
1 Same as logical operation 1
bF-02 16.
Input assignment A 1024
bF-03 16.
Input assignment B
bF-04 16.
Input assignment C
bF-05 16.
Input assignment D
bF-06 16.
Input bit polarity A 0
bF-07 16.
Input bit polarity B
bF-08 16.
Input bit polarity C
bF-09 16.
Input bit polarity D
bF- 10 16.
ON delay time 0.0
bF- 1 1 16.
OFF delay time
bF- 12 16.
Polarity 0
bF- 13 16.
Latch 0
 User-defined bank (udb)
Display Auxiliary
display
Item Settings and descriptions Initial
value
User
setting
Remarks
UDB.AL -
User-defined bits 1 to 8 00000 to 000FF (hexadecimal value) 00000 User-defined bits 1 to 8 are set
at one time.
UDB.0 1 -
User-defined bit 1
On: ON Off: OFF
OFF
UDB.02 -
User-defined bit 2
On: ON Off: OFF
OFF
UDB.03 -
User-defined bit 3
On: ON Off: OFF
OFF
UDB.04 -
User-defined bit 4
On: ON Off: OFF
OFF
UDB.05 -
User-defined bit 5
On: ON Off: OFF
OFF
UDB.06 -
User-defined bit 6
On: ON Off: OFF
OFF
UDB.07 -
User-defined bit 7
On: ON Off: OFF
OFF
UDB.08 -
User-defined bit 8
On: ON Off: OFF
OFF
 Temperature and pressure compensation bank (PV.CMP)
Display Auxiliary
display
Item Settings and descriptions Initial
value
User
setting
Remarks
PV.C.0 1
Compensation method 0: No compensation
1: Temperature compensation
2: Pressure compensation
3: Temperature and pressure compensation
0
PV.C.02
Unit for temperature
correction
0: Celsius (°C) 1: Fahrenheit (°F)
2: Kelvin (K)
0 Setting cannot be changed if PV
1 is a thermocouple or RTD.
PV.C.03
Design temperature for tem-
perature correction
-1999.9 to +3200.0 0.0
PV.C.04
Unit for pressure correction 0: MPa 1: kPa 2: Pa 3: kg/cm
2
4: mmH
2
0 0
PV.C.05
Design pressure for pressure
correction
-1999.9 to +3200.0 0.0
PV.C.06
Decimal point position
(for flow rate setting)
0: No decimal point
1: 1 digit after decimal point
2: 2 digits after decimal point
3: 3 digits after decimal point
4: 4 digits after decimal point
1
PV.C.07
Flow rate scaling low limit -19999 to +32000 0.0 The decimal point position is
determined by the decimal.
PV.C.08
Flow rate scaling high limit 100.0
PV.C.09
Square root extraction
dropout
0.0: Square root extraction is not per-
formed 0.1 to 10.0 %
0.0
PV.C. 10
Filter 0.00: No filter 0.01 to 120.00 s 0.0
PV.C. 1 1
Bias -19999 to +32000 0.0
PV.C. 12
Ratio 0.001 to 32.000 1.000
PV.C. 13
Linearization table group
definition
0: Disabled 1: Group 1 2: Group 2
3: Group 3 4: Group 4 5: Group 5
6: Group 6 7: Group 7 8: Group 8
0
