Azbil SDC45 - Default Chapter; Table of Contents

iii
Contents
The Role of This Manual
Chapter 1. PRELIMINARIES
1-1
 Names and function of parts
1-1
 Method of key operations 1-2
Chapter 2. PARA BANK SETTINGS 2-1
 Mode bank (
MODE) 2-1
 Loop 1 PID bank (L 1.PI D) 2-1
 Loop 2 PID bank (L 2.PI D) 2-4
 SP configuration bank (Spcnf) 2-7
 Event configuration bank (evcnf) 2-8
 Control bank (ctrl) 2-11
 MV bank (Mv) 2-13
 Setup bank (Setup) 2-14
 Priority bank (priOr) 2-15
 PV bank (pv) 2-16
 Output bank (OUt) 2-18
 Position proportional bank (PP) 2-20
 CT input bank (CT) 2-20
 AC input bank (ac) 2-20
 Linearization table bank (tbl) 2-21
 Internal contact input bank (i c) 2-26
 Digital output bank (dO) 2-28
 Logical operation bank (bf) 2-29
 User-defined bank (udb) 2-32
 Temperature and pressure compensation bank (PV.CMP) 2-32
 Input computation bank (I N.FNC) 2-33
 Output computation bank (OT.FNC) 2-35
 Display/key bank (hMi) 2-37
 Operation display switching order bank (dtUrn) 2-39
 User-defined operation display creation bank (UdESI ) 2-40
 RS-485 communication bank (rS485) 2-41
 Lock bank (lOcK) 2-41
 Monitor bank (MOni) 2-42
 Instrument information bank (I d) 2-46
