Chapter 4. STANDARD BIT CODES AND STANDARD NUMERICAL CODES
 Standard numerical codes
The range of the standard numerical codes is 2048 to 3071.
Codes not stated in the list are undefined. Therefore, do not use such codes.
The standard numerical codes are set values common to the following items:
•Output type (
cO-0 2
) of output bank (continuous output)
•Lighting status (
MS-02
) of display and key bank (MS display)
•PV, RSP, RMV assignment (
I Np. 0 1
–
I Np. 03
) in the control bank
•SP tracking signal (
CAS.06
) in the MV bank
•MV tracking signal (
TR-03
) in the MV bank
•Inputs 1 and 2 (
I N-0 1
–
I N-02
) in the input calculation bank and the
output calculation bank
•Displayed data (
UDD-2
,
UDD-4
) in the user-defined operation display
creation bank
Standard
numerical
code
Meaning of standard bit
2304 PV1
2305 PV2/PV21
2320
PV of loop 1 (used for PID control)
2321 PV of loop 2 (used for PID control)
2336 SP of loop 1 (in use)
2337 SP of loop 2 (in use)
2352
SP of loop 1 (finally attained value)
2353 SP of loop 2 (finally attained value)
2384 SP output of loop 1
2416 MV of loop 1
2417 MV of loop 2
2432 Heat MV of loop 1
2433 Heat MV of loop 2
2448 Cool MV of loop 1
2449 Cool MV of loop 2
2464 MFB1 (Motor opening feedback
value 1) (including estimation)
2480 MFB1 (Motor opening feedback
value 1) (measurement value)
2496 CT1 current when output ON
2497 CT2 current when output ON
2512 CT1 current when output OFF
2513 CT2 current when output OFF
2528 Deviation of loop 1 (PV-SP)
2529 Deviation of loop 2 (PV-SP)
2544
AC1 value measurement voltage
2545 AC2 value measurement voltage
2560 AC1 value percent data
2561 AC2 value percent data
2656 Event 1 delay remaining time
2657 Event 2 delay remaining time
2658 Event 3 delay remaining time
2659 Event 4 delay remaining time
2660 Event 5 delay remaining time
2661 Event 6 delay remaining time
Standard
numerical
code
Meaning of standard bit
2662 Event 7 delay remaining time
2663 Event 8 delay remaining time
2664 Event 9 delay remaining time
2665 Event 10 delay remaining time
2666 Event 11 delay remaining time
2667 Event 12 delay remaining time
2668 Event 13 delay remaining time
2669 Event 14 delay remaining time
2670 Event 15 delay remaining time
2671 Event 16 delay remaining time
2720 MV for position proportioning 1
Only SDC45V/46V
Standard
bit code
Meaning of standard bit
2306 PV22
2592 Flow rate (with temperature
pressure compensation)
2599 Input computation result (F01)
2600 Input computation result (F02)
2601 Input computation result (F03)
2602 Input computation result (F04)
2603 Input computation result (F05)
2604 Input computation result (F06)
2605 Input computation result (F07)
2606 Input computation result (F08)
2607 Input computation result (F09)
2608 Input computation result (F10)
2615 Output computation result (F01)
2616 Output computation result (F02)
2617 Output computation result (F03)
2618 Output computation result (F04)
2619 Output computation result (F05)
2620 Output computation result (F06)
2621 Output computation result (F07)
2622 Output computation result (F08)
2623 Output computation result (F09)
2624 Output computation result (F10)
