Chapter 3. SP/EV BANK SETTINGS
 SP group selection bank (SPNO)
Display Loop number
( auxiliary display )
Item Settings and descriptions Initial
value
User
setting
Remarks
SPNO L. 1.
Loop 1 SP group 1 to SP system group (max. 16) 1 When SP group selection is
used, set the SP group selection
priority to "setting value".
SPNO L.2.
Loop 2 SP group 1 to SP system group (max. 16) 1
 Loop 1 multi-SP bank (L 1.LSP)
Display Loop number
( auxiliary display )
Item SP
group
Settings and descriptions Initial
value
User
setting
Remarks
LSP.0 1 L. 1.
LSP 1 SP low limit to SP high limit 0.0 The decimal point position is
determined by the decimal point
position for the loop PV/SP.
PI D.0 1 L. 1.
PID group definition 1 1 to 16 1
LSP.02 L. 1.
LSP 2 Same as SP group 1 0.0 Same as SP group 1
PI D.02 L. 1.
PID group definition 2 1
LSP.03 L. 1.
LSP 3 0.0
PI D.03 L. 1.
PID group definition 3 1
LSP.04 L. 1.
LSP 4 0.0
PI D.04 L. 1.
PID group definition 4 1
LSP.05 L. 1.
LSP 5 0.0
PI D.05 L. 1.
PID group definition 5 1
LSP.06 L. 1.
LSP 6 0.0
PI D.06 L. 1.
PID group definition 6 1
LSP.07 L. 1.
LSP 7 0.0
PI D.07 L. 1.
PID group definition 7 1
LSP.08 L. 1.
LSP 8 0.0
PI D.08 L. 1.
PID group definition 8 1
LSP.09 L. 1.
LSP 9 0.0
PI D.09 L. 1.
PID group definition 9 1
LSP. 10 L. 1.
LSP 10 0.0
PI D. 10 L. 1.
PID group definition 10 1
LSP. 1 1 L. 1.
LSP 11 0.0
PI D. 1 1 L. 1.
PID group definition 11 1
LSP. 12 L. 1.
LSP 12 0.0
PI D. 12 L. 1.
PID group definition 12 1
LSP. 13 L. 1.
LSP 13 0.0
PI D. 13 L. 1.
PID group definition 13 1
LSP. 14 L. 1.
LSP 14 0.0
PI D. 14 L. 1.
PID group definition 14 1
LSP. 15 L. 1.
LSP 15 0.0
PI D. 15 L. 1.
PID group definition 15 1
LSP. 16 L. 1.
LSP 16 0.0
PI D. 16 L. 1.
PID group definition 16 1
