Azbil SDC45 - Page 38

2-30
Chapter 2. PARA BANK SETTINGS
Display Logical opera-
tion number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
bF-0 1 05.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 05.
Input assignment A 1024
bF-03 05.
Input assignment B
bF-04 05.
Input assignment C
bF-05 05.
Input assignment D
bF-06 05.
Input bit polarity A 0
bF-07 05.
Input bit polarity B
bF-08 05.
Input bit polarity C
bF-09 05.
Input bit polarity D
bF- 10 05.
ON delay time 0.0
bF- 1 1 05.
OFF delay time
bF- 12 05.
Polarity 0
bF- 13 05.
Latch 0
bF-0 1 06.
Operation type Same as logical operation 1
1
Same as logical operation 1
bF-02 06.
Input assignment A 1024
bF-03 06.
Input assignment B
bF-04 06.
Input assignment C
bF-05 06.
Input assignment D
bF-06 06.
Input bit polarity A 0
bF-07 06.
Input bit polarity B
bF-08 06.
Input bit polarity C
bF-09 06.
Input bit polarity D
bF- 10 06.
ON delay time 0.0
bF- 1 1 06.
OFF delay time
bF- 12 06.
Polarity 0
bF- 13 06.
Latch 0
bF-0 1 07.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 07.
Input assignment A 1024
bF-03 07.
Input assignment B
bF-04 07.
Input assignment C
bF-05 07.
Input assignment D
bF-06 07.
Input bit polarity A 0
bF-07 07.
Input bit polarity B
bF-08 07.
Input bit polarity C
bF-09 07.
Input bit polarity D
bF- 10 07.
ON delay time 0.0
bF- 1 1 07.
OFF delay time
bF- 12 07.
Polarity 0
bF- 13 07.
Latch 0
bF-0 1 08.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 08.
Input assignment A 1024
bF-03 08.
Input assignment B
bF-04 08.
Input assignment C
bF-05 08.
Input assignment D
bF-06 08.
Input bit polarity A 0
bF-07 08.
Input bit polarity B
bF-08 08.
Input bit polarity C
bF-09 08.
Input bit polarity D
bF- 10 08.
ON delay time 0.0
bF- 1 1 08.
OFF delay time
bF- 12 08.
Polarity 0
bF- 13 08.
Latch 0
bF-0 1 09.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 09.
Input assignment A 1024
bF-03 09.
Input assignment B
bF-04 09.
Input assignment C
bF-05 09.
Input assignment D
bF-06 09.
Input bit polarity A 0
bF-07 09.
Input bit polarity B
bF-08 09.
Input bit polarity C
bF-09 09.
Input bit polarity D
bF- 10 09.
ON delay time 0.0
bF- 1 1 09.
OFF delay time
bF- 12 09.
Polarity 0
bF- 13 09.
Latch 0
