Test Procedure
© b2 electronic GmbHDHV0086 Rev0666
Step Procedure (Congureautomaticsequence)
AS13: Test Parameters – Waveform
Select one of the following output modes:
VLF withstand test
• Sine wave
• Square wave
VLF Tan Delta test
• Sine wave
DC test
• DC+
• DC-
DC test
• DC - vacuum bottle test
AS14: Test Parameters – Frequency
Set the frequency to as close to 0.1Hz as
possible.
• 0.1 Hz/Auto: Recommended setting that
automatically maintains the frequency as
close to 0.1 Hz as possible.
AS15: Store
To store sequence, press “Finish” button.
