Unit Rigging & Assembly
Section Assembly of
Four-Piece Cells
Figure 9. Upper and Lower Assembly for Dual Air Intake FXV3 and CXVT
CriticalSeal(SeeFigure11)
CriticalSeal(SeeFigure10)
Figure 11. Plenum Step Detail
WaterBafe
RiggingGuide
PerimeterSeal
2”x2”Piece
ofFlatButyl
SealerTape
(Allow1”
Overlap)
PerimeterSeal
1”Overlap
PlenumStep
PlenumStepSeal
FlushAgainstStep
Figure 12. Application of Butyl Sealer Tape
FlatButylSealer-
Tape
InsideFace
Aligninsideedge
oftapewithedge
ofatsurface
Figure 10. Perimeter Seal Detail
6. Liftandsettheplenummodule.Centertheplenummoduletransverselyandlongitudinally.Theriggingguides
(Figure 13a)willengagewhentheplenummoduleiswithin2”ofthelowersection.Bolttheplenummoduleinplace
atthefourinternalbracketlocations.SeeFigure 5onpage 5fortypicalboltingdetail.
Figure 13a. Plenum Module Rigging
13b
RiggingGuide
RiggingGuides
Figure 13b. Detail of Receiver/
Slot for Coil Rigging Guide
Receiver/
Slot
forCoil
Rigging
Guide
