SCOPE OF THIS MANUAL
This manual contains installation and operation instructions for the E-Series® Ultrasonic Plus meter. Failure to read and follow
these instructions can lead to misapplication or misuse of this product, resulting in personal injury and damage to equipment.
Proper performance and reliability of the product depend upon installation in accordance with these instructions.
ABOUT THE ESERIES ULTRASONIC PLUS METER
The E-Series Ultrasonic Plus meter uses solid-state ultrasonic transit-time technology to measure cold potable water,
and incorporates an integrated valve into the lay length of the meter. With an ORION® Cellular LTE-M or LTE-MS endpoint
connected to the meter, authorized utility personnel can schedule the integrated valve on the meter to open, close and
partially close via commands sent from BEACON® AMA (Advance Metering Analytics), allowing you to remotely restrict and
restore water service in a secure manner. The modular design of the meter gives utilities the option to order and install a
valve-ready meter first, then install the valve later.
The E-Series Ultrasonic Plus meter can be installed using horizontal or vertical piping, with water flow in the up direction. The
meter will not measure flow when an empty pipe condition is experienced. An empty pipe is defined as a condition when the
flow sensors are not fully submerged.
E-Series Ultrasonic Plus meters comply with the lead-free provisions of the Safe Drinking Water Act, are certified to
NSF/ANSI Standards 61 and 372, and carry the NSF 61 marking. All components of the meter comprise the certified system.
E-Series Ultrasonic Plus meters comply with the applicable portions of the most recent revision of the American Water Works
Association (AWWA) Standard C715.
All electronic components utilized in the E-Series Ultrasonic Plus meter and RF Transceiver design comply with applicable FCC
Part 15 standards and AWWA C707 for encoded remote reading systems.
Safety Information
The installation of the E-Series Ultrasonic Plus meter must comply with all applicable federal, state, and local rules, regulations,
and codes.
WARNING
THIS PRODUCT HAS A MAGNETIC FIELD.
Product Unpacking and Inspection
Upon opening the shipping container, visually inspect the product and applicable accessories for any physical damage such
as scratches, loose or broken parts, or any other sign of damage that may have occurred during shipment.
OTE:N If damage is found, request an inspection by the carrier’s agent within 48 hours of delivery and file a claim with the
carrier. A claim for equipment damage in transit is the sole responsibility of the purchaser.
SYSTEM REQUIREMENTS
• BEACON Advanced Metering Analytics (AMA) - New users see "BEACON First Time Setup" on page 9
• ORION Cellular LTE-M or LTE-MS Endpoints with firmware version 2.0 and higher
Scope of this Manual
Page 3 August 2020 ESM-UM-02156-EN-02
