Badger Meter ER-9 User Manual

Pulse Output Programming
The Pulse Output can be programmed for any engineering unit of measure. A Pulse Output Scale Factor must be calculated and
programmed (Program Mode 6) using the same formula and procedure as described under the Totalizer Scale Factor (Program
Mode 1).
The transmitter pulses per unit in Table 3 apply to the following transmitters:
• FT-1 • FT-1E • FT-2 • PFT-2 • PFT-2E • PFT-3 • FT-420 • PFT-420
Size
(in.)
Meter Model US Gallons Liters Ft
3
1/2 OP 222.960 58.899 1687.857
1/2 OP (FT1 only) 111.500 29.455 834.078
1 OP 76.640 20.246 573.307
2 OP 20.600 5.442 154.099
2 Industrial Turbo 17.360 4.586 129.862
3 Industrial Turbo 12.400 3.276 92.758
4 Industrial Turbo 2.560 0.676 19.150
6 Industrial Turbo 1.080 0.285 8.079
5/8 LP RCDL 229.554 60.641 1717.186
5/8 25 RCDL 198.340 52.396 1484.689
3/4 35 RCDL 126.671 33.463 947.566
1 40 RCDL 89.781 23.717 671.610
1 55 RCDL 58.064 15.339 434.351
1 70 RCDL 46.752 12.350 349.726
1-1/2 120 RCDL 23.867 6.305 178.539
2 170 RCDL 14.565 3.848 108.955
1-1/2 160 Turbo Series 1.537 0.406 11.495
2 200 Turbo Series 1.537 0.406 11.495
3 450 Turbo Series 1.598 0.422 11.955
4 1000 Turbo Series 1.665 0.440 12.455
6 2000 Turbo Series 0.150 0.040 1.122
8 3500 Turbo Series 0.151 0.040 1.133
10 5500 Turbo Series 0.198 0.052 1.481
12 6200 Turbo Series 0.129 0.034 0.963
16 6600 Turbo Series 0.016 0.004 0.116
20 10000 Turbo Series 0.009 0.002 0.067
1/2 Industrial OG 378.5 * 100 * 2831 *
3/4 Industrial OG 249.8 * 66 * 1868 *
1 Industrial OG 249.8 * 66 * 1868 *
1HF Industrial OG 162.8 * 43 * 1217 *
1-1/2 Industrial OG 64.4 * 17 * 481 *
2 Industrial OG 34.1 * 9 * 255 *
3 Industrial OG 11.4 * 3 * 85 *
* If using a PFT-3E transmitter, multiply number by 2.
Table 3: Transmitter pulses per unit
User Manual
Page 11 August 2018 REG-UM-00836-EN-12
