Badger Meter IOG Series - Analog (Model ILR 730)

Register output specifications & wiring Page 15/20
OG_IOG_BA_02_1401
10.3 Analog (model ILR 730)
Register wiring
External DC+: Yellow
External ground: Brown
Analog output: White
DC input: 6 to 24 VDC; 10 to 20mA
Outputs: Analog 4 to 20mA output in loop powered configuration; external load of 50
ohms to 250 ohms; flow rate is linear scaled between 4mA minimum and 20mA
maximum set points; flow rates below programmed minimum read 4mA.
Figure 15: ILR 730 wiring
Yellow
4-20 mA
transmitte
r
8-24V DC in
p
ut
ILR 730
Brown Mass
White
Analog
output
