Badger Meter Vortex VN2000 User Manual

Wiring a Remote Transmitter
Page 14 June 2018VRX-UM-02217-EN-04
WIRING A REMOTE TRANSMITTER
To wire remote electronics, use the supplied cable with the multi-pin connectors. The cable is a double-sided, molded
cordset with a single-keyway, threaded connection. The cable ends are the same. See the VN2000 Transmitter user manual for
instructions on installing, wiring and troubleshooting the transmitter.
MPORTANTI
Do not hook up electronics with the power on.
Insertion Tool
Sensor Element
Remote
Transmitter
Figure 7: Remote version
