Badger Meter Vortex VN2000 User Manual

Part Number Conguration
Page 18 June 2018VRX-UM-02217-EN-04
PART NUMBER CONFIGURATION
- - - - - - - - - - -
VN2000 Hot Tap Insertion Vortex Meter VF
Pipe Line Size (used for meter conguration only)
2 inch A020
3 inch A030
4 inch A040
6 inch A060
8 inch A080
10 inch A100
12 inch A120
14 inch A140
16 inch A160
18 inch A180
20 inch A200
24 inch A240
26 inch A260
28 inch A280
30 inch A300
32 inch A320
36 inch A360
Material
Stainless Steel, Commerical
C
End Fittings
1-1/2 inch NPT NTS
1-1/2 Flange ANSI 150 FAS
1-1/2 Flange ANSI 300 FBS
Process Temperature & Pressure
Standard S
Reserved
None W
Measurement
Volumetric ow rate
V
Mass ow, temperature
T
Heat energy/BTU (not available for sensor replacement)
1
E
Transmitter Type
E
F
Integral, 24V DC
Remote, 24V DC
Cable Length
None (integral/meter mount or replacement sensor)
WW
10 feet/3 m (remote transmitter)
2
AB
30 feet/15 m (remote transmitter)
2
AF
Fluid & Pipe Type
C
H
L
S
G
Liquid-Chilled (not available with Measurement option V)
Liquid-Heating (not available with Measurement option V)
Liquid (available with Measure option V only)
Steam
Gas
Display
S
Standard
Communication/Output
S
M
4-20 mA and Pulse Output
Modbus RTU
Testing & Tagging
Standard Testing G
One internal temperature sensor and one external temperature sensor included.
Specify cable length from sensor to transmitter. Transmitter power 10 foot cable included.
Model
5 inch A050
1
2
BACnet MS/TP
B
