Badger Meter Vortex VN2000 User Manual

Part Number Conguration
Page 19 June 2018 VRX-UM-02217-EN-04
Metric Pipes
- - - - - - - - - - -
VN2000 Hot Tap Insertion Vortex Meter VF
Pipe Line Size (used for meter configuration only)
50 mm D050
80 mm D080
100 mm D100
150 mm D150
200 mm D200
250 mm D250
300 mm D300
350 mm D350
400 mm D400
450 mm D450
500 mm D500
550 mm D550
600 mm D600
650 mm D650
700 mm D700
750 mm D750
800 mm D800
850 mm D850
900 mm D900
Material
Stainless Steel, Commerical C
End Fittings
DN40 Flange PN16 PAS
DN40 Flange PN40 PCS
Process Temperature & Pressure
Standard S
Certification
None W
Measurement
Volumetric flow rate V
Mass flow, temperature T
Heat energy/BTU
1
E
Transmitter Type
Integral, 24VDC E
Remote, 24VDC F
Cable Length
None (integral/meter mount or replacement sensor) WW
10 feet/3 m (remote transmitter)
2
AB
30 feet/15 m (remote transmitter)
2
AF
Fluid & Pipe Type
Liquid-Chilled (not available with Measurement option V) C
Liquid-Heating (not available with Measurement option V) H
Liquid (available with Measurement option V only) L
Steam S
Gas G
Display
Standard S
Communication/Output
4-20 mA and Pulse Output
S
Modbus RTU M
BACnet MS/TP B
Testing & Tagging
Standard Testing G
1 One internal temperature sensor and one external temperature sensor
2 Specify cable length from sensor to transmitter. Transmitter power 10 foot cable included.
