Motorized Linear Actuator baelz 373-E45
4.3 Principle of operation
Motorizedlinearactuatorstooperatecontrolvalvesforowregulationapplicationsincontrol
andprocesstechnology.Theself-lockingthreadedspindle/spindlenutisdrivenbyanelectric
motorviaagearbox.Thisconvertstherotarymovementintoalinearmovement.Load-
dependentlimitswitchesdictatetheendpositions
4.3.1 Manual adjustment
Manualadjustmentmayonlybecarriedoutwhenthemotorisnotinmotion.Forthe
adjustment,unscrewthecapnutfromthetopofthecover,removethehandcrankfromthe
bracketonthebottomoftheactuatorhousingandinsertitintothetubeinthetopofthecover.
Turnthecrankhandleusinggentlepressure.
