Motorized Linear Actuator baelz 373-E45
8.4 Conguration of the DIP switches
=factorysetting
The factory setting of the DIP switches is position 0, as shown.
Fig. 10: Setting the DIP switches
Switch Function Position 1 "ON" Position 0
DIP 1
Setvalueinput:voltage,Vorcurrent,mA? current,mA voltage,V
DIP 2
Setvalueinputstartingat0V/0mAor
2V/4mA?
2-10V/4-20mA 0-10V/0-20mA
DIP 3
Analogueoutputstartingat0V/0mAor
2V/4mA?
2-10Vand/or
4-20 mA
0-10Vand/or
0-20 mA
DIP 4
Directionofcontrolaction:valveclosedwith
drivespindleextendedorretracted?
Drivespindleretracted
→
valveclosed
Drivespindle
extended→
valveclosed
DIP 5
Currentpositionoftheactuatorissavedas
additionalswitchingposition"2EZ-1".See
wiringdiagram,page21.
from0to1→
save"2EZ-1"
=2%
DIP 6
Currentpositionoftheactuatorissavedas
secondadditionalswitchingposition"2EZ-1".
Seewiringdiagram,page21.
from0to1→
save"2EZ-2"
=98%
DIP 7, 8, 9
These3DIPswitchesdenethefunction:
linear/splitrange/11-point/inverted
s.Fig.11,page24
= linear
DIP 10
Denesvalvecharacteristicusingactuator
characteristic,seepage24.
Actuatorcharacteristic
inverseequal
percentage,valve
action linear
Actuatorcharacteristic
linear,valveaction
equalpercentage
DIP 11
SelectsstandardorModbusmode. Modbusmode standardmode
DIP 12
Startsinitializationrun.
Setbackto0afterinitialization
(s.section8.5.2)
from0to1→
startsinitializationrun
N↔S
Selectsnormalorsafetymode position"S"
=safetymode
position"N"
=normalmode
