7. FITTING THE 7020A DIGITAL POSITIONER
Disconnect actuator from power supply before starting work!
Danger
Theseinstructionsapply,giventhatthepotentiometerassemblyhasbeencorrectlyttedas
describedinsection6.1.
● Removetheextensionandthebrasssleeve.
● InserttheM4x5mmscrewintothelimitswitchplate,butdonottightenit.Putthe
bracketinplace.Nowtightenthescrew.
