Motorized Linear Actuator baelz 373-E45
Table 3. Technical Specifications, baelz 7020A
Supply voltage
230VAC-15%/+10%,50/60Hz,
option:115VAC50/60Hz,24VAC50/60Hz
Fuse
internal1.6A/T(slow-blow)
Power consumption
approx.5VA
IP rating
IP42
Ambient temperature
0to50°C
Transport / storage temp.
-25to+65°C
Ambient humidity
5to90%relativehumidity.(non-condensing)
Dimensions WxHxD
approx.105x82x32mm
DI suppy voltage
24VDC,Imax=5mA
Digital input
1congurableusingsoftware,Imax5mA,
low=0...5VDC,high=9...38VDC,Re=5.5kΩ
Digital outputs
2potentialfreeauxiliarychageoverswitches,congurable,max.250VAC,4A
min.contactload:10V/100mA
2 output signals
Output1:0/2...10V/min.ohmicresistance5kΩ
Output2:0/4...20mA/max.ohmicresistance300Ω
Factorysetting:0...10Vand0...20mA
Input signal
0/2...10V/Re63kΩ,0/4...20mA/Re200Ω,measurementaccuracy0.1%
Connection
PUSHINspringterminals,strippinglength8mm
Wiring
WiresizeAWG: min.AWG24;max.AWG16
solidwire/strandedwire: min.0.2mm²;max.1.5mm²
withwireferruleaccordingtoDIN46228/1: min.0.25mm²;max.1.5mm²
withinsulatedwireferruleDIN46228/4: min.0.25mm²;max.0.75mm²
Operation
12DIPswitches/optional:advancedoperationusingRS485andsoftware
Interface
RS485ModbusRTU,Baudrate2400...19200,1start,8piecesofdata,1
stop-bit, no parity
Memory
non-volatilesemiconductor
Weight
approx.0.2kg
8.7 Technical Specications
8.8 Accessories and options
● Freeparameterisationsoftware(ModbusRTU)-InterfaceRS485required!
● ForlaptopswithUSBwerecommendourinterfaceconvertor(OrderNo.5280-051).
