Motorized Linear Actuator baelz 373-E45
8.5.3 Meaning of LED signals
redLED
greenLED
LED
signal
LED
signal
Meaning
1
greenoff
red off
Unitisswitchedoff.
2
green off
redon
Initializationruninprogress.
3
green
ashing
redoff
Unitisnotinitialized.Potentiometerinidealpositionforinitializationrun(between7.5and
17.5%).
4
green
ashing
redon
Unitisnotinitialized.Potentiometernotinidealpositionforinitializationrun.
Initializationstillpossible.
(IftheredLEDisickering,thepositionofthepotentiometerisattheedgeoftheoptimalrangeandthereforeOK.)
5
green
andred
ashing
Errorduringinitialization.Unitisnotinitialized.TheashingredLEDshowsthenumberof
theerrorcode:3ashes,interval,3ashes,interval→errorcode3.Seealsosection8.6.1.
6
green on
redoff
Unitisinitialized.Noerrors.
7
green on
redon
Immediatelyaftertheunitisswitchedon,bothLEDsarelitfor2secondstoshowthatthey
areinworkingorder.
8
greenon
red
ashing
Unitisinitialized.DIP12setto1→errorafterinitializationrun,seesection8.6.1
DIP12setto0→errororalarmduringnormalpositioneroperation,seesection8.5.2.
