Motorized Linear Actuator baelz 373-E45
9. HEATING - RETROFITTING THE HEATING ELEMENT
Preparatorymeasuresbeforetting:
1. Disconnectactuatorfrompowersupply
2. Removethecapnutfromtheactuatorcover
3. Pullandgentlyturncovertoremove
● Screwthetemperaturesensorrmlyintotheholebytheload-dependentlimitswitches.
Fixtheheatingelementinitsplaceonthecoverusingthetwoscrewsprovided.
● Removethescrewfromthelimitswitchboardandreplaceittogetherwiththeterminal
block.
● Connectbothwireendstoterminals(7)and(8).Terminals7and8arethenconnected
totheelectricalsupply.Fixwiringwithcableties.
