Motorized Linear Actuator baelz 373-E45
8.6 Errors
8.6.1 Errors after an initialization run
Followingasuccessfulinitializationrun,onlythegreenLEDislit.
IftheredLEDisashing,thisindicatesanerrorfollowinganunsuccessfulinitializationrun.
Thersterrortooccurduringinitializationisshown.IfthegreenLEDislit,theunithadalready
beeninitializedbeforethecurrentinitializationrun.IfthegreenLEDisashing,theunithadnot
beensuccessfullyinitializedpreviously.
TheredLEDshowserrorsoccuringduringinitializationasfollows:
Errorcode1:
interval interval etc.
Errorcode2:
interval interval etc.
etc.upto...
Errorcode8:
interval interval
etc..
Followinganinitializationrun,theredLEDshowsonlyinitializationerrorsaslongasDIPswitch
12issetto1.Thisenablesacleardifferentiationbetweenerrorsoccuringduringinitialization
andthoseoccuringduringnormalpositioneroperation.SettingDIPswitch12from1backto0
permitstheredLEDtoshowanynormaloperationalerrorsinsteadofinitializationerrorswhich
mayhaveoccured.
Error code Error Corrective action
1 → 1x
Invalidstatusofinitializationrun.Possible
cause:EMI(electromagneticinterference).
Removesourceofinterference.
2 → 2x
SensormalfunctionatanalogueinputAI1:
Nosignalfrompotentiometer.
Checkconnectionterminals91,92,93
(seewiringdiagram,Fig.9,page21).
Replace potentiometer if necessary.
3 → 3x
PotentiometervalueatAI1toosmall.
Possiblecause:EMI.
Removesourceofinterference.
Replace potentiometer if necessary.
4 → 4x
PotentiometervalueatAI1toolarge.
Possiblecause:EMI.
Removesourceofinterference.
Replace potentiometer if necessary.
5 →5x
Wrongdirectionoftravel Checkmotor(97,98,99)andpotentiometer
(91,92,93)connections(seewiringdiagram,
Fig.9,page21).
Removesourceofinterference.
6 →6x
Obstruction:potentiometerormotornotmoving. Checkconnections,setN↔Sswitchto"N",
removeanyobstructions.
7 →7x
Stroketoolong. Fitactuatortoavalvewithnominalstroke
length<22mm.
8 →8x
Stroketooshort. Fitactuatortoavalvewithnominalstroke
length>8,7mm,removeanyobstructions.
