REMOVABLE FREEzER COMPARTMENT
To enlarge the cooling compartment, just
remove the freezer compartment.
• Unlock the freezer compartment door
using a screwdriver (Fig. 24).
• Remove the freezer compartment door.
• Unlock the freezer compartment shelf on
both sides.
• Pull out the freezer compartment shelf.
REMOVING THE CRISPER
REMOVAL
• Pull out the vegetable bin up to the end
top.
• Press in the end stop (1) in both slide rails.
• Remove the vegetable bin.
• Insert the vegetable bin in the rails and
push it in completely.
• After the engagement, the vegetable
bin is secured against being pulled out
completely again.
