Operating mode
In operating mode (expert mode), trained staff can adjust
all advanced functions.
The operating menu differentiates between switching and
analog operating mode. The settings are performed with
the menu item
SoA
(Adjusting the operating mode,
section7.6.1).
Switching hysteresis is fixed at 15digits.
Calling up operating mode
► Press and hold the
button for at least 8s.
⇒ The remaining time is shown in the display (in
seconds).
⇒ The first menu item (
i n
) is displayed (analog value
in digits).
Navigating the menu
Taste Funktion Anzeige
und
Browse menu items at the
same level.
Yellow
LED segments
Select parameters within a
menu item
Orange
LED
segments
Switch to parameter input
within a menu item.
Yellow
segments
flash
Exit parameter input mode. Yellow
segments
light up
Switch to the main menu.
Change to a submenu item.
Returning to the submenu
activates the most recently
used submenu item.
[ ]
Change to a submenu item.
Returning to the submenu
activates the most recently
used submenu item.
Tab. 7-1: Navigating the menu
Exiting operating mode
► Confirm
End
with the button.
⇒ All settings are saved; the display indicates
run
and
the sensor dampening rate in digits. After
10minutes of inactivity, the operating mode is
exited without saving any teach values.
