Operating mode (continued)
7.1 Overview of menu structure
7.1.1 Switching mode
Ebene Display Function Section
1 2
1
i n88888
Analog sensor value (in
digits)
7.2
2
t S88888
Teaching in switchpoints 7.3.1
3
SP 18888
Manually adjusting
switchpoint 1
7.4
4
SP28888
Manually adjusting
switchpoint 2
7.5
5
[ 8 ]c onf
Submenu: Configuration 7.6
a
SoA 8888
Adjusting the operating
mode (switching or
analog)
7.6.1
b
out 8888
Adjusting the switching
power amplifier type/
analog output
7.6.2
c
Mod8888
Adjusting the switching
mode
7.6.3
d
E t t 8888
Setting external triggers 7.6.4
e
don8888
Setting the switch-on
delay
7.6.5
f
dof 8888
Setting the switch-off
delay
7.6.6
6
[ 8 ]di SP
Submenu: Display
settings
7.7
g
F W88888
Display of software
version
7.7.1
h
HW88888
Display of hardware
version
7.7.1
i
L uM8888
Adjusting the luminosity 7.7.2
j
1808888
Display text rotation
(0/180°)
7.7.3
k
VaL8888
Dampening rate display
in RUN mode
7.7.4
7
E nd8888
Closing the menu 7.8
Tab. 7-2: Menu structure: Switching mode
7.1.2 Analog mode
Ebene Display Function Section
1 2
1
Nno8888
Analog sensor value (in
digits)
7.2
2
t A88888
Teaching in switchpoints 7.3.2
3
[ 8 ]c onf
Submenu: Configuration 7.6
a
SoA8888
Adjusting the operating
mode (switching or
analog)
7.6.1
b
SA88888
Adjusting the switching
power amplifier type/
analog output
7.6.2
4
[ 8 ]di SP
Submenu: Display
settings
7.7
g
F W88888
Display of software
version
7.7.1
h
HW88888
Display of hardware
version
7.7.1
i
L uM8888
Adjusting the luminosity 7.7.2
j
1808888
Display text rotation
(0/180°)
7.7.3
k
VaL8888
Dampening rate display
in RUN mode
7.7.4
5
E nd8888
Closing the menu 7.8
Tab. 7-3: Menu structure: Analog mode
7.2 Analog sensor value (in digits)
i n
/
Ano
Indicates a value dependent on the sensor, distance
(relative measurement), or dampening.
Display range: 0…4095
