5 Process Data
5.4. Data
Configuration
BNI EIP-202-105-
Z015
Please enter the following values to your Control System. They describe the datasizes for
input, output and config data.
Instance ID
Data length
INPUT
100
6
OUTPUT
101
6
5.5. Process Data
Inputs
BNI EIP-202-105-
Z015
There are 6 bytes of Input data. Have a look at the tables below to see the mapping of the
process data inputs.
Byte
Bit
Description
7
6
5
4
3
2
1
0
0
0
I34
0
I24
0
I14
0
I04
Handshake data
I04  Status on port 0 pin 4
1
0
I74
0
I64
0
I54
0
I44
2
0
O34
0
O24
0
O14
0
O04
Overload status
O04  Overload on port 0 pin 4
Only if port is configured as output
3
0
O74
0
O64
0
O54
0
O44
4
0
0
0
0
0
0
PS
PA
Power status
PS: Sensor power
PA: actor power
5
0
0
0
0
0
0
0
0
Reserved
5.6. Process Data
Output
BNI EIP-202-105-
Z015
There are 6 bytes of output data. Have a look at the tables below to see the mapping of the
process data outputs.
Byte
Bit
Description
7
6
5
4
3
2
1
0
0
0
O34
0
O24
0
O14
0
O04
Output data
O04  Output on port 0 pin 4
1
0
O74
0
O64
0
O54
0
O44
2
0
R34
0
R24
0
R14
0
R04
Restart
Restart output here after a
detected short-circuit
3
0
R74
0
R64
0
R54
0
R44
4
0
0
0
0
0
0
0
0
Reserved
5
0
0
0
0
0
DL
GO
RO
Display Control
DL: Display lock / PLC lock
GO: Green LED on Display on
RO: Red LED on Display on
