Resetting all values (reset)
NOTICE!
Interference in function
Resetting the values while the system is running may
result in malfunctions.
► Stop the system before performing the reset.
The reset function can be used to restore all the settings
to the factory settings. For a reset the magnet may also be
located outside the measuring range.
Displayed values (example)
At 0…10 V At 4…20 mA
5.39 V 9.15 mA
Activate reset
► Simultaneously activate
a
and
b
for at least 4s.
>4s
a
b
10.50 V 3.60 mA
Reset
► Simultaneously activate
a
and
b
for at least 4s.
>4s
a
b
0.00 V 4.00 mA
After activation:
⇒ All values are reset.
9.89 V 19.13 mA
⇒ Current position value is displayed.
⇒ Reset is deactivated.
Abort reset
Resetting can be aborted without any changes
being saved after the Activate reset step.
► Briefly activate
a
and
b
simultaneously (<1s).
<1s
a
b
⇒ Current position value is displayed.
BTL7-A/C/E/G5 __ -M ____ -K(8)-SR32/SR115/___
Micropulse Transducer - Rod Style

Balluff BTL7 Series Specifications

General

Measurement Principle	Magnetostrictive
Resolution	Up to 1 μm (depending on model)
Operating Temperature	-40°C to +85°C
Protection Class	IP67
Housing Material	Aluminum
Output Signal	Analog
Supply Voltage	10V to 30V DC
