Balluff BTL7 Series User Manual

www.balluff.com 21english
10.6 Dimensions, weights
Rod diameter 8mm or 10.2mm
Nominal length
For Ø8mm 25…1016mm
For Ø10.2mm 25…7620mm
Weight
(depends on length)
Approx. 2kg/m
Housing material Stainless steel
Flange material Stainless steel
Rod material Stainless steel
Rod wall thickness
For Ø8mm 0.9mm
For Ø10.2mm 2mm
Young's modulus Approx. 200kN/mm
2
Housing mounting Flange with 6 holes
BTL7-…-K__
Cable material PUR;
cULus20549
80°C, 300V,
internal wiring
Cable temperature –40°C…+90°C
Cable diameter Max. 7mm
Permissible bending radius
Fixed routing ≥35mm
Moved ≥105mm
BTL7-…-F__
Cable material PTFE
No UL approval available
Cable temperature –55°C…+200°C
Cable diameter Max. 7mm
Permissible bending radius
Fixed routing ≥35mm
Moved No permissible bending
radius
10
Technical data (continued)
BTL7-A/C/E/G5 __ -M ____ -K(8)-SR32/SR115/___
Micropulse Transducer - Rod Style

Balluff BTL7 Series Specifications

General

Measurement Principle	Magnetostrictive
Resolution	Up to 1 μm (depending on model)
Operating Temperature	-40°C to +85°C
Protection Class	IP67
Housing Material	Aluminum
Output Signal	Analog
Supply Voltage	10V to 30V DC
