Balluff BTL7 Series User Manual

www.balluff.com 25english
12
Type code breakdown
BTL7 - E 5 0 0 - M0500 - K - SR32
Micropulse transducer
Interface:
A = Analog interface, voltage output 0…10 V
G = Analog interface, voltage output −10…10 V
C = Analog interface, current output 0…20 mA
E = Analog interface, current output 4…20 mA
Supply voltage:
5 = 10…30VDC
Output gradient:
00 = Rising (e.g. C_00 = 0…20 mA); only with BTL7-C/E
10 = Rising + falling (e.g. A_10 = 10…0 V and 0 to 10 V); only with BTL7-A/G
70 = Falling (e.g. C_70 = 20…0 mA); only with BTL7-C/E
Nominal length (4-digit):
M0500 = Metric specification in mm, nominal length 500mm (M0025…M7620)
Rod version, fastening:
K = Flange with 6 holes, O-ring, rod diameter 10.2mm
K8 = Flange with 6 holes, O-ring, rod diameter 8mm
Electrical connection, radial:
SR32 = 8-pin, M16 plug per IEC130-9
SR115 = 8-pin, M12 plug
K05 = Cable, 5m (PUR)
F05 = Cable, 5m (PTFE)
BTL7-A/C/E/G5 __ -M ____ -K(8)-SR32/SR115/___
Micropulse Transducer - Rod Style

Balluff BTL7 Series Specifications

General

Measurement Principle	Magnetostrictive
Resolution	Up to 1 μm (depending on model)
Operating Temperature	-40°C to +85°C
Protection Class	IP67
Housing Material	Aluminum
Output Signal	Analog
Supply Voltage	10V to 30V DC
