B&G Network DEPTH - Page 35

INSTALLATION DATA
Gasket
Bulkhead
Fit the gasket around
the mounting bracket
82.0mm
82.0mm
Mounting bracket Rubber Gasket
Gasket
Display Unit
Sun-cover
Self-tapping screws
Mounting bracket
70.0mm hole
Network connector Network & Power connector
Locking stud fixing
110.0mm
110.0mm
25.0mm 65.0mm
Network QUAD
LIGHTS
ENTER
SETUPTIMER
TEMP
SPEED DEPTH
Depth sensor connector
Speed sensor connector
610-HB-0503-05
35
