Creating/editing a custom page
A custom page is created in a two steps process:
Replacing one of the active pages with a template page (ref
above)
Selecting data for the template page's field(s)
Ú
Note: If the template page has multiple data fields you use the
arrow keys to select active field.
You can later change the data for any fields in a custom page.
Changing the range scale on analog pages
You can change the range scale for some full screen analog pages
by pressing the arrow keys.
Ú
Note: If the actual recorded data is greater than the selected
analog scale, the analog needle will remain at the highest point
on the scale. The digital window in the center of the display will
show the actual value.
26
Pages | Triton2 Operator manual

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the B&G Triton2 and is the answer not in the manual?

B&G Triton2 Specifications

General IconGeneral
Resolution320 x 240 pixels
InterfaceNMEA 2000
Power Supply12V DC
Waterproof RatingIPX7
BacklightLED
Display Size4.1 inches
Operating Voltage9 to 16V DC
