Technical specification

Dimensions

Refer to "Dimensional drawing" on

page 83

Weight 0.32 kg (0.7 lbs)

Power consumption 1.8 Watts

Key backlight off 0.54 W

Key backlight max 1.35 W

Network load 3 LEN

Color Black

Display

Size 4.1" (diagonal). 4:3 Aspect ratio

Type

Transmissive TFT-LCD. White

LED backlight

Resolution 320 x 240 pixels

Illumination

White for day mode. Red, green,

blue or white for night mode

Environmental protection

Waterproof rating IPx7

Humidity 100% RH

Temperature

Operating -25° to +65ºC (-13°F to +149 ºF)

Storage -40° to +85ºC (-40°F to +185 ºF)

Technical specification | Triton2 Operator manual
