Bandit
38
Copyright 12/17
MODELS 2890SP/2900T MAINTENANCE
1. Grease grading blade pivot bushings with 1 to 2 shots.
2. Check grinder bearings and grinder sheaves (belt driven cutter wheels only).
3. Check bearing and bearing lock collars (belt driven cutter wheels only).
4. Check hydraulic function pressures. Set to specied PSI (bar).
MONTHLY CHECK LIST
Every month these checks must be made:
OK REPAIRED
1. Replace hydraulic lter(s) after rst 10 hours then quarterly or every 400 hours.
Located in the hydraulic tank.
2. Replace high pressure and charge lters after rst 10 hours, then quarterly or
every 400 hours. There are three located under the oil cooler housing cover
and the inspection cover between the hydraulic tank and the control box.
3 MONTH CHECK LIST
Every three months these checks must be made:
OK REPAIRED
1. Drain and clean the fuel tank.
2. Change hydraulic oil and ush the hydraulic tank.
3. Replace hydraulic suction screen(s) annually or every 2000 hours.
YEARLY CHECK LIST
Every year these checks must be made:
OK REPAIRED
BOLT TORQUE CHART
(THESE TORQUES ARE BASED ON DRY, CLEAN THREADS)
DESCRIPTION BOLT SIZE TORQUE (FT.-LBS.) TORQUE (Nm)
Cutter Wheel Revolution Lead Tooth Nut 5/8” - 18 NF 200 271
Cutter Wheel Revolution Side Tooth Nut 5/8” - 18 NF 125 169
Cutter Wheel Green Tooth Pocket Bolts 5/8” - 18 NF 180 - 200 244 - 271
Cutter Wheel Green Tooth Nut 50 67
Cutter Wheel Coupler (Beltless) 30 41
Stub Shaft (Beltless) 1/2” - 13 NC 75 102
Stub Shaft Brace (Beltless) 5/8” - 11 NC 170 230
Cutter Wheel Bushing (Belt Driven) 9/16” - 12 NC 84 114
Cutter Wheel Bearing Bolts (Belt Driven) 5/8” - 11 NC 190 258
Cutter Wheel Bearing Set Screws (Belt Driven) 57 77
Hydrostatic Motor Cog Bushing (Belt Driven) 35 47
Cutter Shaft Cog Bushing (Belt Driven) 84 114
Engine Isolator Hold Downs 1/2” - 13 NC 95 129
Lug Nuts 1/2” - 20 NF 90 - 120 122 - 163
Before tightening bolts be sure you have the correct size bolt for the correct amount of torque.
Use only factory approved knives and hardware.
