MODELS 2890SP/2900T
CHECKING HYDRAULIC FUNCTION PRESSURE
HYDRAULICS
FIGURE 2 - MODEL 2900T CUSTOM MANIFOLD VALVE
FIGURE 3
FIGURE 1 - MODEL 2900T PULSAR VALVE
Main
Relief
Test Port
Main Test
Port
Left Track
Test Port
Right Track
Test Port
Swing
Relief
Auxiliary
Pump Relief
Cutter Wheel
Lift Relief
Grading
Blade Relief
Auxiliary
Test Port
Pump Charge
Test Port
Tracks In / Out
Relief
(View looking at bottom of valve)
Main Test
Port
Pump Charge
Test Port
Main
Relief
Swing
Relief
Grading
Blade Relief
Cutter Wheel
Lift Relief
Tracks In / Out
Relief
Left Track
Right Track
