Bandit
69Copyright 12/17
MODELS 2890SP/2900T
LOCATION PART NUMBER DESCRIPTION
CUTTER WHEEL ARM COMPONENTS
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
BELTLESS DRIVE
1. 992-2001-02 Chip Pan
2. 992-3004-97 Side Chip Curtain
3. 992-3004-96 Rear Chip Curtain
4. 992-3005-30 Chip Pan Strap
5. 992-2001-09 Cutter Wheel Motor Guard
6. 992-3004-78 Stub Shaft Brace
7. 992-3004-79 Backer Plate
8. 992-2001-00 Cutter Wheel Guard
9. 992-2000-96 Cutter Wheel Arm Assembly
10. 900-4907-60 3/16” x 3” Cotter Pin
11. 900-4907-23 1 1/2”-6NC Slotted Hex Nut
12. 900-4913-47 1 1/2” Mill Carb Washer
13. 989-300982 Cutter Lift Pivot Pin
14. 900-1908-37 Split Bushing - 1 3/4” OD x 1 1/2” ID x 1 1/2”
15. 900-1912-83 Split Bushing - 1” OD x 3/4” ID x 2”
16. 900-3934-20 Swing Cylinder Pin
17. 900-3958-81 Swing Cylinder
18. 900-4913-27 Custom Retainer Washer - 1 3/4” OD x 3/8” ID
19. a. 992-3004-43 Pivot Pin
b. 900-4900-06 Grease Zerk
20. 992-3004-44 Pivot Pin Keeper
21. 900-1911-59 Split Bushing with Grease Groove - 1 1/4” OD x 1” ID x 1”
22. 900-4901-47 3/4” Mill Washer
23. 900-4911-75 3/16” x 2” Cotter Pin
24. 204-3000-66 Top Cutter Wheel Lift Cylinder Pin
25. 204-3000-67 Bottom Cutter Wheel Lift Cylinder Pin
26. 900-3940-29 Cutter Wheel Lift Cylinder
27. a. 992-1000-80 Swing Pivot Assembly - 2890 (Includes 14, 15, 18 - 25)
b. 992-2001-28 Swing Pivot Weldment - 2890
c. 992-1000-79 Swing Pivot Assembly - 2900 (Includes 14, 15, 18 - 25)
d. 992-2001-27 Swing Pivot Weldment - 2900
28. 992-3004-87 Side Chip Curtain - Swing-Out Option
29. 992-3002-72 Chip Pan Strap - Swing-Out Option
30. 992-2001-06 Chip Pan for Swing-Out Option
