MODELS 2890SP/2900T
TYPICAL HYDRAULIC RELIEF PRESSURE SETTINGS
TYPICAL HYDRAULIC FLOWS AND RPM SETTINGS
(Approximate, For Reference Only, Engine At Full RPM)
and hoses should be re-checked for leaks and clearances.
DO NOT UNDER ANY CIRCUMSTANCES OVER-SET THESE RELIEF PRESSURES, BECAUSE IT WILL
CAUSE DAMAGE TO COMPONENT PARTS AS WELL AS HYDRAULIC PARTS.
subject to change!
NOTICE
NOTICE
CAUTION
!
HYDRAULICS
HYDRAULICS
Equipment Model 2890 (Remote) 2890 (Swing Out) 2900T
Charge
PSI (bar)
350 - 450
(24 - 31)
350 - 450
(24 - 31)
350 - 450
(24 - 31)
Cutter Wheel Pump
GPM (LPM)
47
(179)
47
(179)
47
(179)
Auxiliary Pump
GPM (LPM)
11.5
(54.5)
15.5
(70.5)
2.4 - 9.7
(9.2 - 36.8)
Cutter Wheel
PSI (bar)
5700
(393)
5700
(393)
5700
(393)
Function Main Relief
PSI (bar)
2800
(193)
2800
(193)
P1 DTS Block
P2 DTS Block/
Pulsar Valve
3500 (241) 2800 (193)
Cutter Wheel Up/Down Relief
PSI (bar)
2400
(165)
2800
(193)
2400
(165)
Swing Setting
PSI (bar)
1600
(110)
2800
(193)
2000
(138)
Track In/Out
PSI (bar)
N/A N/A
2650
(183)
Steering
PSI (bar)
2800
(193)
2800
(193)
N/A
Blade Up/Down
PSI (bar)
1600
(110)
2800
(193)
1800
(124)
Cutter Wheel
RPM
1450 1450 1450
Auxiliary Pressure
PSI (bar)
P1
PRESET PRESET PRESET
P2
2800 (193) 2800 (193) 2800 (193)
To Next Page
