Bandit 2890SP - Page 83

Bandit
77Copyright 12/17
MODELS 2890SP/2900T
LOCATION PART NUMBER DESCRIPTION
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
1. 900-4909-42 1/2”-20NF Lug Nut
2. a. 900-5908-54 20.5” x 8” - 10” Tire & 5 Bolt Rim (Specify Left or Right)
b. 900-5908-52 20.5” x 8” - 10” Industrial Lug Tire Only
c. 900-5908-53 10” x 6”, 5 Bolt Rim Only
3. a. 992-1000-30 Steering Wheel Hub
b. 900-5905-97 1/2”-20NF Stud
4. 204-2000-30 Steering Motor Mount for Parker Hydraulic Motors - Right Side (Includes 8)
5. 900-3973-35 Parker Non-Braking Drive Motor
6. 204-2000-31 Steering Motor Mount for Parker Hydraulic Motors - Left Side (Includes 8)
7. 900-4900-80 1”-8NC Nylock Lock Nut
8. 900-1919-25 Split Bushing - 1-1/4” OD x 1” ID x 1/2”
9. 900-1902-50 Split Bushing - 1 1/4” OD x 1” ID x 1 1/2”
10. 900-4913-38 1”-8NC x 5 1/2” Hex Head Bolt
11. 900-4920-00 5/8” x 1 1/4” x 1/2”-13NC Socket Shoulder Screw
12. 203-1000-03 Steering Tie Rod Assembly (Includes 11 & 13 - 15)
13. 900-4917-69 Right Side Tie Rod End
14. 900-4917-70 Left Side Tie Rod End
15. 900-4906-84 1/2”-13NC Grade C Automation Lock Nut
16. 204-2000-32 Steering Pivot Pin
17. 900-1912-84 Split Bushing - 1-3/4” OD x 1 1/2” ID x 1”
18. 204-2000-29 Steering Pivot for Parker Hydraulic Motors
19. a. 993-200023 Steering Cylinder Pin - 4” Long
b. 900-4911-74 Cotter Pin
20. a. 993-200022 Steering Cylinder Pin - 5 1/8” Long
b. 900-4911-74 Cotter Pin
21. 900-3937-68 Steering Cylinder
22. 992-2001-24 Steering Motor Mount for White Hydraulic Motors - Right Side (Includes 8)
23. 992-2001-25 Steering Motor Mount for White Hydraulic Motors - Left Side (Includes 8)
24. 992-2000-58 Steering Cylinder Pin - 3 5/8” Long
25. 900-3941-16 White Non-Braking Drive Motor
26. 992-2000-72 Steering Pivot for White Hydraulic Motors
MODEL 2890SP
STEERING COMPONENTS
