Bante Instruments 9 Series - Meter Overview; Connectors

General Guide I 04
USB cable, power adapter
pH electrode, pH buffer reagents
Ion selective electrode, standard solutions, ionic strength adjuster 
Conductivity electrode, conductivity standard solutions
Dissolved oxygen electrode, electrolyte solution, membrane cap
Temperature probe
Model / Components
1
2
3
4
5
6
920/930
•
•
•
931
•
•
•
932
•
•
•
950
•
•
•
980
•
•
900
•
•
•
•
•
901
•
•
•
•
902
•
•
•
•
903
•
•
•
•
904
•
•
•
•
 Cyanide and sulfide ion meters do not provide above solutions.
Meter Overview
1 Sensor connections
2 Base plate of electrode arm
3 Display
4 Membrane keypad
Connectors
1 Socket for pH, ORP or ion selective electrode (BNC)
2 Socket for temperature probe (3.5 mm jack)
3 Socket for dissolved oxygen electrode (6-pin DIN)
4 Socket for conductivity electrode (6-pin DIN)
5 Socket for reference electrode (3.5 mm jack)
6 USB-B interface to the power adapter or computer
