3. Press【】/【】to find CONFIGURATION, press [MENU] to confirm.
4. Input the correct configuration password (setting by programming), press [MENU] to confirm.
5. Press【】/【】to find the group call list, press [MENU] to confirm.
6. Press【】/【】to select the group call list, which can delete or add the group member. Press【】/【】
to add group call list, which can add the new group call.
Main technological specification
Frequency range
VHF:136-174MHz/ UHF:400-480MHz(Dual band)
Memory Channel
Up to 3000
Frequency Stability
±1.0ppm
Operating Temperature
-30℃~+60℃
Operating Voltage
DC 7.4V
Demission
133*62*36mm ( no including the antenna)
Weight
Transmission
Output power
High:5W Low:1W
Output Consumption
Analog≤1.6A Digital≤0.9A
Consumption
≤0.18A
FM modulation
16K¢F3E@25KHz 141K¢F3E@20KHz 11K¢F3E@12.5KHz
4FSK digital modulation
12.5KHz for data:7K60FXD 12.5KHz for data and voice :7K60FXE
Modulation Distortion
≤5%
Signal-to-noise(wide/narrow)
≥45dB@25KHz ≥40dB@12.5KHz
Adjacent Channel power
≤-65dB ≤-60dB
Audio Response
+1~3dB
Antenna Port Spurious
9KHz-1GHz: ≤-36dBm 1GHz-12.75GHz: ≤-30dBm
Digital Protocol
ETSI-TS102 361-1,-2,-3
Vocoder type
AMBE+2
TM
Reception
Analog receive sensitivity
-122dBm (12dB SINAD)
Digital receive sensitivity
-120dBm (BER≤5%)
Audio power
1W
Audio distortion
<10%
Audio response
+1～-3dB
Signal imitation
≥70dB
Intermediation (Wide/ narrow)
≥62dB/≥58dB
Adjacent channel selectivity
≥65dB/≥60dB
Receive Current
≤380mA
PM noise
≥45dB@25KHz /≥40dB @12.5KHz
All specifications may be modified without prior notice or liability.
Troubleshooting:
