The function and use method of operation device and meter is listed as follows:
No.
Name
Function
Use method
1
Inching pedal
Couple or uncouple the
transmission.
When the pedal is pressed,
the transmission is
uncoupled.
2
Button for
stopping engine
Stop the engine.
Pull the button to stop the
engine.
3
Brake pedal
Brake the truck.
Depress the pedal to brake
the truck.
4
Parking brake lever
Park the truck.
Pull the lever backward fully.
5
Hand wheel
adjusting lever
Adjust the angle of
steering wheel.
6
Shift lever
Change the travel
direction.
Pull the lever forward, the
truck travels forward.
7
Oil pressure
indicator
Indicate the pressure of
engine oil.
Pressure is insufficient, it
lights up.
8
Fuel gauge
Indicate the fuel capacity.
Ignition switch is set at on.
9
Charge signal
Indicate the battery
condition of charge.
Lamp comes on when the
ignition switch is set at on.
10
Neutral signal
Indicate the neutral
position.
Shift lever is in neutral
position, it lights up.
11
Air filter indicator
(option)
It will warn when the air
filter is blocked.
Exceed standard resistance,
it flashes.
12
Water temp. gauge
Indicate the temperature
of engine coolant.
Ignition switch is set at on.
13
Sedimentor
indicator (option)
Indicate water amount in
sedimentor.
Water reaches to a certain
level, it lights up
14
Hour meter
Shift lever is in neutral
position.
Ignition switch is set at on.
15
Horn button
Control the horn.
Press it to sound horn.
16
Turn signal lever
Indicate the turning
direction.
Pull the lever, the turn signal
light blinks.
17
Accelerator pedal
Increase the engine speed
Depress the pedal to
increase the speed.
18
Lift lever
Control lift cylinder.
Pull backward to lift, pull
forward to decline.
19
Tilt lever
Control tilt cylinder.
Pull the lever backward to tilt
the mast backward.
