Baoli CPCD 80 - Page 36

30
Fig.1.2 A-6BG1QC diesel engine
Main performance and disposition of A-6BG1QC
Model
A-6BG1QC
Type
4-cycle,water-cooled,overhead valve
No. of cylinder—bore×stroke
6-105mm×125mm
Total displacement (L)
6.494
Compression ratio
17
Performance
Rated speed
rpm
2000
Rated output
kw
82.3
Max. torque (N.m/rpm)
416/1400-1600
Full-load fuel consumption
g/kwh
233
No-load Min. speed
rpm
700
Weight
kg
450
Dimension
mm
1129.5×672.0×860.0
Injection start pressure
kg/cm
2
kg/cm
2
Compress pressure
kg/cm
2
kg/cm
2
