Barco CX-50 - CX-50 specifications

R5900096 /00 CX-50 25
2.2 CX-50 specifications
Base Unit
Dimensions (HxWxD) 39mm x 200mm x 202mm
Power supply Standard 110/220 V AC plug
Power consumption Operational: 50W (max)
Standby: <8W (networked standby), < 0.5W (deep standby mode)
Weight 900 gr
Operating system Windows 8/8.1/10. macOS 10.13 and higher.
Android v9 and higher (ClickShare app).
iOS 12 and higher (ClickShare app)
Video outputs 4K UHD (3840*2160) @ 30Hz. HDMI 1.4b
Video inputs 1920x1080 @30Hz. HDMI 1.4b
Audio output USB, SPDIF, jack, HDMI
USB 3 X USB-A, 1 X USB-C
ClickShare Buttons 2
ClickShare App Desktop & Mobile
Native protocols Airplay, Google Cast, Miracast
Noise Level Max. 25dBA @ 0-30°C
Max. 30dBA @ 30-40°C
Authentication protocol WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X using the ClickShare Button in network
integration mode
Wireless transmission
protocol
IEEE 802.11 a/g/n/ac and IEEE 802.15.1
Reach Adjustable with signal strength modulation; max. 30m (100 ft) between
ClickShare Button and ClickShare Base Unit
Frequency band 2.4 GHZ and 5 GHz (DFS)
Frequency band 2.4 GHZ and 5 GHz (DFS channels supported in select number of
countries)
Connections 1x Ethernet LAN 1Gbit
1x USB Type-C 2.0 (back); 2x USB Type A 2.0 (back); 1x USB Type A 2.0
(front)
Audio analog line out on mini jack socket (3.5mm), digital S/PDIF
Temperature range Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)
Humidity Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
Anti-theft system Kensington lock
Certifications FCC/CE
CX-50 Specifications
